9 Menus
9.10.4 Saving the controller configuration
(Contr. config.SD)
Line Display:
1: Contr.cong.SD
2:
3: n/y
4:
Operation:
Menu One menu level higher
/ Select yes/no
Confirm selection
9.10.5 Loading the controller configuration
(Contr. config. SD)
Line Display:
1: Contr.cong.SD
2:
3: n/y
4:
Operation:
Menu One menu level higher
/ Select yes/no
Confirm selection
9.10.2 Delete logbook
Line Sample display:
1: Delete logbook
2:
3: n/y
4:
Operation:
Menu One menu level higher
/ yes / no
Confirm selection
Line Selection (submenu)
1 Display logbook
2 Delete logbook /
3 All devices -> SD
4 Contr.cong.SD
5 Contr.cong.<- S D
6 Dev.cong.->SD
9.10.3 All devices -> SD
Save all systems and controller configurations.
The more numbers of systems are installed the more time for
memory is needed!
First, the CG Controller configuration is saved on SD. Then the
device configuration and the texts are read and saved. With the
help of this the following information gets read and saved from
all devices:
•CG-Controllerconfigurationonmemorycard
•Luminairetexts
•Circuitnames
•DLS,TLS,3PhW-names
•Deviceconfiguration
Line Display:
1:
2: Contr.cong.SD
3: – – – – – – – – – –
4:
Operation:
Menu One menu level higher
Confirm selection
Line Selection (submenu)
1 Display logbook
2 Delete logbook
3 All devices->SD
4 Contr.cong.SD
5 Contr.cong.<- S D
6 Dev.cong.->SD
Line Selection (submenu)
1 Display logbook
2 Delete logbook
3 All devices->SD
4 Contr.cong.SD
5 Contr.cong.<- S D
6 Dev.cong.->SD
Line Selection (submenu)
1 Display logbook
2 Delete logbook
3 All devices->SD
4 Contr.cong.SD
5 Contr.cong.<- S D
6 Dev.cong.->SD
ATTENTION!
After this action the logbook has been deleted irrevocable!
