Eaton CEAG CG-Controller User Manual

15
Manual CEAG CG-Controller for CG 2000/ZB-S 30080001458 (C) July 2016 www.ceag.de
9 Menus
Line Selection (main menu)
1 Test menu ∕
2 Block, reset
3 Info device
4 Setup CG-Controller
5 Setup device
Operation:
n Flashing cursor = current
cursor position/selection
Menu Back to the main screen
 Cursor position lower
 Cursor position higher
Select menu item (Enter)
Operation:
Menu One menu level higher
 Cursor position Line 1 → 3
 Cursor position Line 3 → 1
 /  Selection in Line
1: Next/previous device
3: Switch backing forth
between “no/yes”
Starts the functiontest or
durationtest
Operation:
Menu One menu level higher
 /  Selection in Line
3: Cancel „no/yes“
 Exits the durationtest that
iscurrently running
Operation:
Menu One menu level higher
 /  Selection in Line
3: Switch backing forth be-
tween “no/yes”
 Starts the functiontest or
durationtest
9.4 «Test» menu
The menu displays in the
«Test» menu and its sub-
menus are described below.
Submenus that work in a
similar manner are combined
into a single description.
9.4.3 Cancelling the operating duration test
9.4.1 Starting the functiontest FT or
durationtest DT for individual devices
9.4.2 Starting the functiontest FT or
durationtest DT for all devices
Line Display:
1 Durationtest
2 Cancel
3 All devices n/y
4
Line Selection (submenu)
1 Functiontest all dev
2 Functiontest one dev∕
3 Durationtest all dev
4 Durationtest one dev
5 Cancel durationtest
Line Selection (submenu)
1 Functiontest all dev
2 Functiontest one dev
3 Durationtest all dev ∕
4 Durationtest one dev
5 Cancel durationtest
Line Selection (submenu)
1 Functiontest all dev
2 Functiontest one dev
3 Durationtest all dev
4 Durationtest one dev
5 Cancel durationtest ∕
Line Display:
1 Functiontest
2 All devices
3 Start n/y
4
Line Display:
1 Device address 1↔
2 Functiontest
3 start n/y
4 Device name
