Manual CEAG CG-Controller for CG 2000/ZB-S 30080001458 (C) July 2016 www.ceag.de
9 Menus
9.10.7 Sending a device configuration from
theCG-Controller to the device
(dev. config. ← SD)
The following message appears while the configuration of the
device is being read and saved to the SD:
If a fault is detected while reading from the SD, the following
message appears:
9.10.6 Saving the device configuration in the
CG-Controller to SD (dev. config. → SD)
The following message appears while the configuration of the
device is being read and saved to the SD:
If a fault is detected while writing to the SD, the following
message appears:
Line Selection (submenu)
3 All devices→SD
4 Contr.cong.→SD
5 Contr.cong.←SD
6 Dev.cong.→SD
7 Dev.cong.←SD ∕
8 Text←SD
9 Text→SD
Line Display
1 Device address 1
2 Dev.cong.←SD
3 Start n/y
4 Device name
Line Display
1
2 Dev.cong.←SD
3 Percentage: 01%
4 Est. duration 11 min.
Operation:
Menu Cancel
(you may need to hold the key
down for longer)
Line Display
1
2 Dev.cong.←SD
3 SD read fault
4 Continue with 
Operation:
Menu One menu level higher
 Confirm fault
Line Selection (submenu)
3 All devices→SD
4 Contr.cong.→SD
5 Contr.cong.←SD
6 Dev.cong.→SD ∕
7 Dev.cong.←SD
8 Text←SD
9 Text→SD
Line Display
1 Device address 1
2 Dev.cong.→SD
3 Start n/y
4 Device name
Line Display
1
2 Dev.cong.→SD
3 Percentage: 01%
4 Est. duration 33 min.
Operation:
Menu Cancel
(you may need to hold the key
down for longer)
Line Display
1
2 Dev.cong.→SD
3 SD write fault
4 Continue with 
Operation:
Menu One menu level higher
 Confirm fault
Operation:
Menu One menu level higher
 Line 1:
 Next device
 Previous device
Line 3:
 /  Yes / No
 Confirm selection
Note:
Cancelling the device
configuration by press-
ing the Menu key will
result in an incomplete
data transfer!
Operation:
Menu One menu level higher
 Line 1:
 Next device
 Previous device
Line 3:
 /  Yes / No
 Confirm selection
