9 Menus
Line Display:
1 Password:
2 Activated
3 Password (6 digits)
4 Password: 123456
9.8.8.4 Menu password inquiry
If the password is activated, functions on the CG-Controller are
not possible unless the password has been previously entered.
For emergency cases: If you have forgotten your password, your
dealer can ask for a general password for you from the manufactu-
rer/customer service.
Operation:
0 ... 9 Password entry
Accept
9.8.10 Network Master
The CG-Controller is in Master mode by default. This mode is
selected if the emergency lighting system does not have any addi-
tional control monitoring system available.
If the CG-Controller is being operated in parallel with other control
monitoring units, it must work in Observer mode.
The following items are not supported in Observer mode:
•CG-Controllerlogbook
•Nextfunctiontestinthe«SetupCG-Controller»menu
•Nextdurationtestinthe«SetupCG-Controller»menu
Line Selection (submenu)
8 Serial number
9 Customer service info.
10 Password
11 NID receive
12 Network Master
Line Sample display:
1 CG-Controller Z720.A
2 Operate as master?
3 n/y
4
Operation:
Menu One menu level higher
 /  Select no/yes
 Confirm selection
Line Sample display:
1 Receive
2 Service Request MSG
3
4 Please wait...
Operation:
Menu One menu level higher
9.8.9 NID receive
9.8.9.1 Waiting for a service request message
Line Selection (submenu)
6 Serial number
7 Cust o mer service info.
8 Password
9 NID receive ∕
10 Network Master
9.8.9.2 Service Request Message received
Line Sample display:
1 Receive
2 Service Request MSG
3 ID=00 00 33 98 68 00
4  Back
Operation:
Menu One menu level higher
