Eaton DC1-124D1FN-A20N - System Overview

1 DC1 device series
1.2 System overview
10 DC1 frequency inverter 10/12 MN04020003Z-EN www.eaton.com
1.2 System overview
Figure 1: DC1 frequency inverters system overview
a DC1-… frequency inverters
b DX-LN-… main chokes, DX-LM3-… motor reactors, DX-SIN3-… sinusoidal filters
c DX-BR… braking resistance
d DXC-EXT-… expansion module
e DXC-NET-… fieldbus connection
f DX-COM-STICK communication module and accessories (e. g. DX-CBL-… connection cable)
g DE-KEY-… keypad (external)
Ready
I
O
A
⏚
L1/L
L2/N
L3
⏚
U
V
W
1
2
3
4
5
6
7
8
9
10
11
⑤
④
⑥
①
②
③
⑦
