Eaton DC1-124D1FN-A20N - Dimensions and Frame Size

9 Appendix
9.2 Dimensions and frame size
170 DC1 Frequency Inverter 10/12 MN04020003Z-EN www.eaton.com
9.2 Dimensions and frame size
Figure 87: Size FS1
Figure 88: Size FS2
VAR
EMC
1234567891011
⌀6 mm
⌀12 mm
(⌀0.47
"
)
(⌀0.24
"
)
81 mm
50 mm
(3.19")
(1.97")
124 mm (4.88")
4 mm (0.16")
7 mm (0.28")
170 mm
184 mm
(6.9")
(7.24")
EMC
VAR
L2/N L3DC- L1/L
DC+ BR U V W
12345678910111213
14 15 16 17 18
COM
⌀6 mm
⌀12 mm
(⌀0.47
"
)
(⌀0.24
"
)
186 mm (7.32")
107 mm
75 mm
(4.21")
(2.95") 5 mm (0.2")
215 mm
231 mm
(8.46")
(9.09")
8 mm (0.31")
