8 CANopen
8.4 Error Messages
166 DC1 Frequency Inverter 10/12 MN04020003Z-EN www.eaton.com
8.4 Error Messages
Frequency actual value (Index 200B
hex
)
The frequency reference value is specified in hertz with a single decimal
place.
Example: 125
dez
12.5 Hz
Current (Index 200D
hex
)
The current is specified with one decimal place.
Example: 34 3.4 A
Failure code
[hex]
Value shown on display Description
00 StoP Stop, ready for operation
01 OI-b Brake chopper overcurrent
02 OL-br Braking resistance overload
03 O-I • Overcurrent at frequency inverter output
• Motor overload
• Overtemperature on frequency inverter heat sink
04 I_t-trP Motor, thermal overload
05 PS-trP Internal fault (power section)
06
O_Uo IE Overvoltage (DC link)
07
U_Uo IE Undervoltage (DC link)
08 O-t Overtemperature (heat sink)
09 U-t Undertemperature (heat sink)
0A P-dEF Default settings (parameters have been loaded)
C0 E-triP external error message
0C SC-trP Field bus error
0D – reserved
0E P-LOSS Phase failure (mains side)
0F
SPIn-F Motor pick-up control function (for catching spinning motors)
failed
10
th-Flt Internal thermistor fault (heat sink)
11 dAtA-F EEPROM checksum fault
12 4-20 F Analog input:
• Out-of-range value
• Wire breakage (4-mA monitoring)
