Eaton DC1-124D1FN-A20N - DC1 Device Series; Rated Data

1 DC1 device series
1.4 Rated data
DC1 frequency inverter 10/12 MN04020003Z-EN www.eaton.com 15
Catalog number examples
Inscription Meaning
DC1-124D1FN-A20N DC1 = DC1 series frequency inverter
1 = Single-phase mains connection / three-phase motor connection
2 = 230 V mains voltage category (200 - 240 V ±10 %)
4D1 = 4.1 A rated operational current (output current)
F = Internal radio interference suppression filter (RFI, EMC measure)
N = No internal brake chopper
A = LED display (7-segment) on operating unit
20 = Protection type IP20 / NEMA 0
N = Standard basic device
1)
DC1-S27D0FB-A20N DC1 = DC1 series frequency inverter
S = Single-phase mains connection / single-phase motor connection for AC motors
2 = 230 V mains voltage category (200 - 240 V ±10 %)
7D0 = 7 A rated operational current (output current)
F = Internal radio interference suppression filter (RFI, EMC measure)
B = Internal brake chopper. An external braking resistor (optional) is required for this
function.
A = LED display (7-segment) on operating unit
20 = Protection type IP20 / NEMA 0
N = Standard basic device
1)
DC1-34024NB-A20N DC1 = DC1 series frequency inverter
3 = Three-phase mains connection / three-phase motor connection
4 = 400 V mains voltage category (380 - 480 V ±10 %)
024 = 24 A rated operational current (output current)
N = No internal radio interference suppression filter (RFI)
2)
B = Internal brake chopper. An external braking resistor (optional) is required for this
function.
A = LED display (7-segment) on operating unit
20 = Protection type IP20 / NEMA 0
N = Standard basic device
1)
DC1-342D2FN-A6SN DC1 = DC1 series frequency inverter
3 = Three-phase mains connection / three-phase motor connection
4 = 400 V mains voltage category (380 - 480 V ±10 %)
2D2 = 2.2 A rated operational current (output current)
F = Internal radio interference suppression filter (RFI, EMC measure)
N = No internal brake chopper
A = LED display (7-segment) on operating unit
6S = Protection type IP66 / NEMA 4X with switches (mains switch, enable/phase
sequence, potentiometer) for local control
N = Standard basic device
1)
1) Standard version = with Modbus
2) For frequency inverters without an internal EMC filter, external measures for complying with the relevant limits
concerning electromagnetic compatibility (EMC) must be taken for operation as per IEC/EN 61800-3
(e.g., external radio interference suppression filter).
￫
An external radio interference suppression filter is required for
DC1… N… for operation as per IEC/EN 61800-3.
