Eaton easyControl EC4-200 User Manual

10/10 MN05003003Z-EN
7
About this manual
List of revisions
The following significant amendments have been introduced since previous issues:
Additional documentation
At different points in this manual, references are made to more
detailed descriptions in other manuals. This documentation is
stored as a PDF file when the product CD is installed on your PC.
To find documentation choose the following in the Windows Start
menu:
Programs
l Moeller Software l easy Soft CoDeSys l
Documentation…
It is also possible to download the PDF files from the FTP server.
This always provides the latest data.
ftp://ftp.moeller.net/DOCUMENTATION/AWB_MANUALS/
Concrete information regarding communication with CAN stations
and their configuration can be found in the following listed
documentation:
• AN27K19GB: Communication between two PLCs using
network variables via CAN (AN2700K19GB.PDF)
• AN27K20GB: Coupling multiple stand-alone PLCs
(CAN-Device) via CANopen (AN2700K20GB.PDF)
• Engineering of CAN stations (AN2700K27GB.PDF)
(To be found in Windows start menu under Programs
l
Moeller Software l easy Soft CoDeSys l Application
examples…)
• MN05010001Z-EN (previously AWB2786-1554GB):
Library description CANUser.lib, CANUser_Master.lib.
The functions of the CANUser.lib and CANUser_Master.lib
libraries enable you to access CAN objects directly.
(To be found in Windows start menu under Programs
l
Moeller Software l easy Soft CoDeSys l Documentation…)
Edition date Page Keyword new Modification
12/06 87 EC4-200 network modules
03/07 9 Addition of types EC4P-222-… j
14 Ethernet interface j
15 Cable connections j
59 Browser commands for Ethernet j
67 Startup.INI mit with Ethernet entries j
104 Character sets j
01/08 29 Selecting or toggling between menu items j
33 System menu j
49 START, COLD START, WARM START, STOP j
50 Interrupt inputs I1 … I4 j
51 Timer interrupt j
87 Chapter 17: "The easyNet network" and
Chapter 18: "Programming via easyNet (routing)“
are omitted.
You will find this information in far greater detail in the manual
MN05006004Z-EN (previously 08/07 AWB2786-1593en)
" Data transfer between easy and IEC PLCs (easyNet)".
j
10/10 all Change to Eaton notation j
