Eaton easyControl EC4-200 User Manual

Appendix
10/10 MN05003003Z-EN
96
Technical data
Climatic environmental conditions
(Cold to IEC 60068-2-1, Heat to IEC 60068-2-2)
Operational ambient temperature
Installed horizontally/vertically
°C, (°F) –25 to 55, (–13 to 131)
Condensation
Prevent condensation with suitable measures
LCD display (reliably legible) °C, (°F)
0 to 55, (–32 to 131)
Storage/transport temperature °C, (°F)
–40 to 70, (–40 to 158)
Relative humidity (IEC 60068-2-30), non-condensing %
5 to 95
Air pressure (in operation) hPa
795 to 1080
Ambient mechanical conditions
Degree of protection (IEC/EN 60529) IP20
Vibrations (IEC/EN 60068-2-6)
Constant amplitude 3.5 mm Hz 5 to 9
constant acceleration 1 g Hz
9 to 150
Shock (IEC/EN 60068-2-27)
Sinusoidal 15 g/11 ms
Shocks
18
Drop (IEC/EN 60068-2-31) Drop
height
mm
50
Free fall, packaged (IEC/EN 60068-2-32) m
1
Mounting position
horizontal,vertical
Electromagnetic compatibility (EMC)
Electrostatic discharge (ESD),
(IEC/EN 61000-4-2, severity level 3)
Air discharge kV 8
Contact discharge kV
6
Electromagnetic fields (RFI),
(IEC/EN 61000-4-3)
V/m
10
Radio interference suppression
Limit value class
EN 55011, EN 55022
Class B
Fast transient burst (IEC/EN 61000-4-4, severity level 3)
Power cables kV 2
Signal cables kV
2
Surge (IEC/EN 61000-4-5, degree of severity 2) kV
0.5 symmetrical
1 asymmetrical
Line-conducted interference (IEC/EN 61000-4-6) V 10
Insulation resistance
Clearance in air and creepage distances EN 50178
Insulation resistance
EN 50178
Overvoltage category/degree of pollution
II/2
Tools and cable cross-sections
Solid, minimum to maximum mm² 0.2 to 4
AWG
22 to 12
Flexible with ferrule, minimum to maximum mm² 0.2 to 2.5
AWG 22 to 12
Factory wiring: AWG
30
