10/10 MN05003003Z-EN
9
1 Device application
The controllers of the EC4-200 series are programmable switching
and control devices. They can be used in domestic applications,
machine building and plant construction. An EC4-200 controller
can be used as a stand-alone controller or connected to remote
input/output devices via the CANopen interface. This interface also
allows you to communicate with other PLCs (with a CANopen
interface).
The EC4P-222-... controller types have an additional Ethernet
interface.
From version 2.0 of the operating system the controllers have the
following features:
Connection of expansion devices/controllers via easyLink
Connection of the MFD-CP4 multi-function display via the
multi-function interface
Transparent mode via the multi-function interface
Direct access to local I/O and the high-speed counters
Integration in the easyNet network via the easyNet/
CAN interface
Controllers from version 2.10 can be connected to the ASI,
PROFIBUS-DP, CAN or DeviceNet networks with suitable network
interfaces.
The controller is programmed with the easySoft CoDeSys
programming software. This software should be installed on a
standard PC with the Windows NT, 2000 or XP operating system.
Further information on the software is provided in the manual for
the programming software (MN05010003Z-EN; previously
AWB2700-1437GB).
This software provides you with a simple entry in the IEC
programming languages such as:
Instruction List (IL)
Function Block Diagram (FBD)
Ladder Diagram (LD)
Structured Text (ST)
Sequential Function Chart (SFC).
This provides a large number of operators such as:
Logic operators such as AND, OR,
Arithmetic operators such as ADD, MUL, …
Comparison operators such as <,=, >
You use the programming software to create, test and document
a project. Functions for analog processing, closed-loop control and
function blocks such as timers, counters simplify programming.
EC4-200 part number overview
The EC4-200 series contains controllers with different displays and
the type and number of inputs/outputs.
Part no.
Features
Keys/display
Transistor outputs
Relay outputs
Analog output
Ethernet connection
EC4P-221-MTXD1 x 8
EC4P-221-MTXX1
8
EC4P-221-MRXD1
x 6
EC4P-221-MRXX1
6
EC4P-221-MTAD1
x 8 x
EC1P1-MTAX1
8 x
EC4P-221-MRAD
x 6 x
EC4P-221-MRAX1
6 x
EC4P-222-MTXD1
x 8 x
EC4P-222-MTXX1
8 x
EC4P-222-MRXD1
x 6 x
EC4P-222-MRXX1
6 x
EC4P-222-MTAD1
x 8 x x
EC1P1-MTAX1
8 x x
EC4P-222-MRAD
x 6 x x
EC4P-222-MRAX1
6 x x
