Interactive display
10/10 MN05003003Z-EN
84
PROGRAM Visualization (***************)
VAR
xIsDisplayEnabled :BOOL;
fbDisplayPage1 :Disp_DisplayPage;
byError :BYTE;
siValue :SINT;
END_VAR
------------------------------------------------------------
(* Initialisation in the first cycle after program start *)
IF g_xFirstCycleAfterStartProgram = TRUE THEN
Disp_RegisterVariable('S1', ADR(g_sDisp_String1), DISP_TYP_STRING);
Disp_RegisterVariable('S2', ADR(g_sDisp_String2), DISP_TYP_STRING);
Disp_RegisterVariable('S3', ADR(g_sDisp_String3), DISP_TYP_STRING);
Disp_RegisterVariable('S4', ADR(g_sDisp_String4), DISP_TYP_STRING);
Disp_RegisterVariable('V1', ADR(PLC_PRG.byValue), DISP_TYP_BYTE);
Disp_RegisterVariable('V2', ADR(PLC_PRG.wValue), DISP_TYP_WORD);
Disp_RegisterVariable('V3',ADR(PLC_PRG.dwValue),
DISP_TYP_DWORD);
Disp_RegisterVariable('V4', ADR(PLC_PRG.usiValue), DISP_TYP_USINT);
fbDisplayPage1.aElementDescription[1].sName := 'S1';
fbDisplayPage1.aElementDescription[1].byLine := 1;
fbDisplayPage1.aElementDescription[1].byColumn := 1;
fbDisplayPage1.aElementDescription[2].sName := 'S2';
fbDisplayPage1.aElementDescription[2].byLine := 2;
fbDisplayPage1.aElementDescription[2].byColumn := 1;
fbDisplayPage1.aElementDescription[3].sName := 'S3';
fbDisplayPage1.aElementDescription[3].byLine := 3;
fbDisplayPage1.aElementDescription[3].byColumn := 1;
fbDisplayPage1.aElementDescription[4].sName := 'S4';
fbDisplayPage1.aElementDescription[4].byLine := 4;
fbDisplayPage1.aElementDescription[4].byColumn := 1;
fbDisplayPage1.aElementDescription[5].sName := 'V1';
fbDisplayPage1.aElementDescription[5].byLine := 1;
fbDisplayPage1.aElementDescription[5].byColumn := 13;
fbDisplayPage1.aElementDescription[5].byDigits := 4;
fbDisplayPage1.aElementDescription[5].byPrecision := 1;
fbDisplayPage1.aElementDescription[5].xInputEnable := FALSE;
fbDisplayPage1.aElementDescription[5].diMinInputValue := 1;
fbDisplayPage1.aElementDescription[5].diMaxInputValue := 100;
fbDisplayPage1.aElementDescription[6].sName := 'V2';
fbDisplayPage1.aElementDescription[6].byLine := 2;
fbDisplayPage1.aElementDescription[6].byColumn := 12;
fbDisplayPage1.aElementDescription[6].byDigits := 5;
fbDisplayPage1.aElementDescription[6].byPrecision := 0;
fbDisplayPage1.aElementDescription[6].xInputEnable := TRUE;
fbDisplayPage1.aElementDescription[6].diMinInputValue := 0;
fbDisplayPage1.aElementDescription[6].diMaxInputValue := 33333;
fbDisplayPage1.aElementDescription[7].sName := 'V3';
