9 Menu 4-9 - Other Components
The submenu for configuration of other E*LDS components is called using this button. If a
component has been selected, its "Name" parameter can be changed system-wide using the corresponding
screen:TheassignedCANbusaddress,diversestatusesandoperatingstatusesarealsodisplayed.
Symbol Meaning
The status of the connection (communication) with the node is OK
The status of the connection (communication) with the node is unknown
The node has failed
The node has been unloaded
The status of the node is OK
The node has alarm status
The screen contains the following parameters:
Configuration Case Controllers Entry Default
Name Name of the node, e.g. Deep freeze island
site case
max. 19 characters -
Position Position designation of the node, e.g.
TK_01
5 characters -
Priority Alarm and message priority 0..99 0..99 -
Address CAN bus address 1..99 These fields cannot be edited! -
Serial number Serial number of the controller -
Firmware version Firmware version of the controller -
Integrated using The controller is connected to the system
centre via this interface
-
Pack number Pack membership for the pack -
The following components are displayed:
Virtus 5
Operator terminals (e.g. AL 300)
Virtus5LANgateway(softwaremodule)
Remote control using terminal mode
The terminal mode screen is opened using the Remote Control button. All parameters of the nodes can be
configured in the terminal mode. For detail information about remote control using the terminal mode, see
chapter Remote control of E*LDS components (terminal mode).
