Text input
For fields that enable input of texts, the text input is also possible using the alphanumeric keyboard. Letters are
generated by multiple tapping of the digit buttons. Confirm with the ENTER button to apply the entered values /
text. Upper case and lowercase can be toggled by tapping the MODE button.
ENTER button Letters / characters
0 äöüß0 space character
1 1
2 abc2
3 def3
4 ghi4
5 jkl5
6 mno6
7 pqrs7
8 tuv8
9 wxyz9
- . _ -
, Insert space character
Delete input text
The MODE button and - must be tapped simultaneously to delete the complete text line. A character is deleted
using the button combination MODE and , .
Cancelling an entry
The entry of a value can be cancelled by tapping the ESC button. The value is not applied.
Exit from the menus and operating screens
Tap the ESC button to exit from menus and operating screens. This returns to the next higher-level menu.
Exit from terminal mode
The terminal mode is ended using the "Back" button at the top left and the entry screen of the selected E*LDS
component is displayed again. The main menu is displayed by tapping the "Home" button; see chapter Status
bar and quick info, page 71 Status bar and quick info.
Tip: The parameters of the case controller for name, position and priority can be very comfortably
configured using the configuration screen in the respective submenu of the E*LDS component (e.g.
Menu 4-2, 4-3 or 4-4).
If no button has been tapped for a period of 10 minutes, the terminal mode is ended automatically and
the main menu is displayed. Any running entry by a user is cancelled and inputs already made are
discarded.
