4 Menu 4-4 - Receiver Module Wireless Sensors
The submenu for configuration of the receiver modules and the wireless sensors is called using this
button. All important parameters and the statuses of the receiver modules and wireless sensors are displayed
there. Receiver modules can be added using the "New entry" button. Already added receiver modules can be
selected and configured using the corresponding screen. The assigned CAN bus address, diverse statuses and
operating statuses are also displayed.
Symbol Meaning
The status of the connection (communication) with the node is OK
The status of the connection (communication) with the node is unknown
The node has failed
The node has been unloaded
The status of the node is OK
The node has alarm status
The screen contains the following parameters:
Configuration Pack Controller Entry Default
Name Name of the node, e.g.
Receiver_module_01
max. 19 characters -
Position Position designation of the node, e.g.
WR_01
5 characters -
Priority Alarm and message priority 0..99 0..99 -
Address CAN bus address 117..120 These fields cannot be edited! -
Serial number Serial number of the receiver module -
Firmware version Firmware version of the receiver module -
Integrated using The receiver module is connected to the
system centre via this interface
-
Remote control using terminal mode
The terminal mode screen is opened using the Remote Control button. In the terminal mode, all parameters of
the receiver module including the associated wireless sensors can be configured. For more information, see
chapter Remote control of E*LDS components (terminal mode). The assigned CAN bus address, diverse
statuses and operating statuses are also displayed.
Any receiver module including the associated wireless sensors can be removed from the system using
the "Delete" button. A receiver module can only be deleted if it has previously been switched off and
accordingly signalled as failed, see menu!
