Note: In the example here, the first relay output of the SIOX extension module is used as a defrost timer for a
case controller. For further details about the configuration of the SIOX, see chapter SIOX - connection to the
system centre.
Relay output Terminal No. Function
Changeover contacts
Without switch With switch
1 16, 18, 15 Week timers
(e.g. for defrosting, lighting, car park lighting)
or
for load shedding
2 26, 28, 25
3 36, 38, 35
4 46, 48, 45
Normally open contacts
Without switch With switch
5 53, 54 13, 14
6 63, 64 23, 24
7 73, 74 33, 34
8 83, 84 43, 44
