DUS 60 Digital Ultrasonic Diagnostic Imaging System User Manual Vascular Measurements and Calculations
- 134 -
2. In the vascular menu, select Vert A.
3. Measure Vert A, in the method of D trace measurement.
Reference Section 6.6.3, Generic Measurements in PW Mode
4. The results are displayed in measurement result window.
5. To begin a new Vert A measurement, repeat steps 1 through 3. You can measure a maximum
of one group of data.
13.1.5. UPPER
To measure UPPER:
1. Press Measure to activate obstetric measurement.
2. In the vascular menu, select UPPER.
3. Measure UPPER, in the method of D trace measurement.
Reference Section 6.6.3, Generic Measurements in PW Mode
4. The results are displayed in measurement result window.
5. To begin a new UPPER measurement, repeat steps 1 through 3. You can measure a maximum
of one group of data.
13.1.6. LOWER
To measure LOWER:
1. Press Measure to activate obstetric measurement.
2. In the vascular menu, select LOWER.
3. Measure LOWER, in the method of D trace measurement.
Reference Section 6.6.3, Generic Measurements in PW Mode
4. The results are displayed in measurement result window.
5. To begin a new LOWER measurement, repeat steps 1 through 3. You can measure a
maximum of one group of data.
DUS 60 Digital Ultrasonic Diagnostic Imaging System User Manual Vascular Measurements and Calculations
- 135 -
13.2. Vascular Report
After finishing the vascular examination, the system generates a vascular worksheet.
Roll the trackball to highlight Vascular Worksheet, and press Set to display Vascular
Worksheet dialog box, as shown below:
Figure 13-2 Vascular Worksheet
The diagnosis editing column displays the cursor “І”, and you can enter diagnosis information.
To print the report:
Press Print in the vascular worksheet.
Printing reference Section 5.8, Printing.
13.3. Others
Select Others to enter another application measurement.
