M3A Vital Signs Monitor User Manual Introduction
- 24 -
Bottom panel
There are battery compartment and fuse box on the bottom panel.
Figure 3-11 Bottom Panel
3.5 Built-in Rechargeable Battery
3.5.1 Battery Safety Information
WARNING
1 Do not unplug the batteries when the monitor is working. The unexpected power
supply off can not impact on the normal monitor working, if it has battery for standby.
2 Stop using the battery if abnormal heat, odor, discoloration, deformation or abnormal
condition is detected during use, recharge, or storage. Keep it away from the monitor.
3 Make sure the monitor is used in the appointed range of voltage, so the effect of
power supply can be ignored.
4 Before using the rechargeable lithium-ion battery (hereinafter called battery), be sure
to read the user manual and safety precautions thoroughly.
5 Do not connect the positive (+) and negative (-) terminals with metal objects, and do
not put the battery together with metal objects, which can result in short circuits.
6 Do not place battery in the monitor with the (+) and (-) in the wrong way around.
7 Do not heat or throw battery into fire.
8 Only use EDAN approved rechargeable batteries for the monitor.
Battery
compartment
cover
Fuse box
