3.4 Interfaces
For the convenience of operator, interfaces of different functions are in different sites of the
monitor.
Sensor port on the front panel
Figure 3-9 Sensor Connectors
Connectors for cables and sensors are as shown in Figure 3-9.
1. SpO
2
sensor connector ①
2. NIBP cuff connector ②
WARNING
Only connect the device to EDAN supplied or recommended accessories.
