M3A Vital Signs Monitor User Manual TEMP Monitoring (Optional)
- 69 -
Message
Cause
Alarm Level
What to do
TEMP
SENSOR OFF
After the sensor
temperature reaches
Predict value, it descends
to the value lower than
Predict value.
Medium
Reconnect the sensor and
make sure that the cable is
properly connected.
Prompt:
Message
Cause
Ready to TEMP
predict
The monitor prompts it after taking the sensor out of the bracket and
warm-up is over.
TEMP Predict
complete
After the Predict measuring is over, the data and message display on
the interface.
TEMP alarm off
The alarm of TEMP is turned off.
10.2 TEMP Monitoring with TH Module
10.2.1 Introduction
M3A with the TH module (Infrared Ear Temperature Module) takes a temperature in the ear.
Diagram of the Infrared Ear Thermometer
WARNING
1 Keep the probe covers away from children.
2 Do not reuse the disposable probe covers.
Batter Cover
Pin Hole

EDAN M3A Specifications

General

Type	Vital Signs Monitor
SpO2 Measurement Range	0-100%
Parameters	SpO2, Pulse Rate, Temperature
Pulse Rate Measurement Range	30 to 250 bpm
Temperature Measurement Range	0 to 50°C
Power Supply	AC 100-240V, 50/60Hz
Battery Life	Up to 8 hours
