EDAN M3A User Manual

M3A Vital Signs Monitor User Manual TEMP Monitoring (Optional)
- 68 -
10.1.4.2 Alarm Information and Prompts
WARNING
In monitoring mode, no physiological alarms are available.
Physiological alarms:
Message
Cause
Alarm Level
TEMP HIGH
Measuring value of TEMP is above upper alarm limit.
Medium
TEMP LOW
Measuring value of TEMP is below lower alarm limit.
Medium
Technical alarms:
Message
Cause
Alarm Level
What to do
TEMP
COMM STOP
TEMP module failure or
communication failure.
High
Stop using measuring function
of TEMP module; notify
biomedical engineer or
Manufacturer’s service staff.
TEMP
EXCCED
LIMIT
The TEMP value is
beyond the range of +25
C ~ +45 C.
Medium
Put the sensor into the sensor
bracket, take it out and
measure again.
TEMP NO
SENSOR
TEMP sensor is not
connected to the TEMP
module.
Low
Connect the sensor and the
monitor well, and measure
again.
AMBIENT
TEMP HIGH
The Sensor temperature is
higher than +40 C.
Low
Put the sensor into the sensor
bracket, measure again after
the ambient temperature
reaches normal value.
AMBIENT
TEMP LOW
The Sensor temperature is
lower than +10 C.
TEMP
SENSOR
ERR
The TEMP sensor cannot
work properly.
Medium
Put the sensor into the sensor
bracket, take it out and
measure again. If the problem
persists, stop using measuring
function of TEMP module;
notify biomedical engineer or
Manufacturer’s service staff.
TEMP
HEATER
ERR
Malfunction in the
warm-up circuit.
Medium

EDAN M3A Specifications

General

Type	Vital Signs Monitor
SpO2 Measurement Range	0-100%
Parameters	SpO2, Pulse Rate, Temperature
Pulse Rate Measurement Range	30 to 250 bpm
Temperature Measurement Range	0 to 50°C
Power Supply	AC 100-240V, 50/60Hz
Battery Life	Up to 8 hours
