101
Parameter
Function
Baud Bit
You can select corresponding baud bit here.
Parity
There are five options: none/odd/even/space/mark.
System default setup is:
 Function: Console.
 Data bit: 8
 Stop bit: 1
 Baud bit: 115200
 Parity: None.
7.3.2.5 Network
Network interface is shown as in X462H462H462HFigure 7-32X.
Figure 7-32
Please refer to the following sheet for detailed information.
Parameter
Function
Ethernet
Please select the network card first.
DHCP
Dynamically get IP address. You can get the device IP from
the DHCP server if you enabled this function.
TCP Port
Default value is 37777.
HTTP Port
Default value is 80.
UDP Port
Default value is 37778.
Max Connection
Network user max amount. The value ranges from 0 to 10.
O means there is no user can access current device.
Remote
Host
Multiple
cast
group

Set MULCAST address and port.

Enable MULCAST function.
