Edwards APG200 - Performance Data; Mechanical Data

Characterisc
Pressure range Accuracy
Filament
LC
10 mbar to 100 mbar ±50% reading
1 x 10
-3
mbar to 10 mbar
±15% r
eading
1 x 10
-4
mbar to 1 x 10
-3
mbar
±50% r
eading
Table 5 APG200 with standard voltage output
Characterisc
Pressure range
Voltage output
Filament
X (Log-linear with pressure) M or MP
5 x 10
-4
mbar to 1000 mbar
X (Log-linear with pr
essure) LC
1 x 10
-4
mbar to 1000 mbar
[blank] (Non-linear) M or MP
1 x 10
-3
mbar to 1000 mbar
[blank] (Non-linear) L
C
1 x 10
-4
mbar to 1000 mbar
Table 6 APG200 with matched voltage output
Characterisc
Pressure range
Voltage output
Filament
O or G (Log-linear with pressure) M or MP or LC
5 x 10
-4
mbar to
1000 mbar
Q (Log-linear with pr
essure) M or MP
5 x 10
-4
mbar to
1000 mbar
Q (Log-linear with pr
essure) LC
1 x 10
-4
mbar to
1000 mbar
3.4 Mechanic
al data
Table 7 Mechanical data
Characterisc
Value Units
Dimensions Refer to Figure: Dimensions (mm) mm
Enclosure rang IP40 -
Mass
£ 200
g
In
ternal volume of tube
Flange
NW16 3.3
cm
3
NW25 3.3
1/8" NPT 3.8
4VCR 3.6
8VCR 5.5
Bare tube 4.8
DN16CF 3.3
07/2021 - ©Edwards Limited
Page 13D1G0000880_A
D1G0000880_A - Technical data
