Table 12 Transistor setpoint variants ([blank] characterisc)
Parameter
Data
Open collector transistor 1 (Quanty)
Maximum external load rang 48 V d.c. maximum, 100 mA
Back EMF suppression diode*
minimum surge rang 1 A
minimum reverse voltage rang 100 V
* Recommended when external DC relay is connected, refer to Figure: 9 way D-sub
connector with setpoint transistor and Figure: RJ45 connector with dual relays.
Table 13 Solid state relay variants (“S” characterisc)
Parameter
Data
Solid State relay 2 (Quanty)
Form
Single Pole Single Throw (SPST), Normally
Open (N.O.)
Rang 48 V d.c. maximum, 500 mA
Relay on series resistance
Typical 0.2 W, maximum 0.3 W
07/2021 - ©E
dwards Limited
Page 16D1G0000880_A
D1G0000880_A - Technical data
