Edwards APG200 User Manual

Table 15 Pins on the gauge electrical connector
Connector 9 way D-sub male RJ45 8-way
Characterisc
[blank]
Setpoint transistor
[S]
Dual relays
[blank]
Setpoint transistor
[S]
Dual relays
Pin Refer to Figure: Electrical connectors
1 Setpoint output signal Relay 1 N.O. Electrical supply posive
2 ID resistor Electrical supply ground (0 V)
3 Electrical supply posive Pressure measurement output signal
4 Electrical supply ground (0 V) ID resistor
5 Pressure measurement output signal Signal ground
6 Not connected Relay 1 common Setpoint output signal Relay 1 N.O.
7 Not connected Relay 2 common Remote calibraon input Relay 2 N.O.
8 Signal ground Not connected Relay common
9 Remote calibraon input Relay 2 N.O. - -
07/2021 - ©Edwards Limited
Page 19D1G0000880_A
D1G0000880_A - Inst
allaon
