EFI Pro 32r - Page 125

Printer Operations
Document ID: OMM-00165 Rev. C Pro 32r Operations Guide 125
6.8.4 Multi-layer - Day-Night on Backlit media
Figure 6-27
1. Open the Grouping dialog box
2. Name the group, and select the Type: Multi-layers and Day-Night on
Backlit media
3. Click OK. The Multi-layer Group Settings opens.
4. Click the “+” button to add the files. The Jobs are automatically mirrored
and placed in the correct order.
5. Set the files and click OK to add the Multi-layer Job to the printing Queue.
6. Print.
Figure 6-28
