Figure 7-31
Double-sided Printing
Document ID: OMM-00165 Rev. C Pro 32r Operations Guide 163
Automatic
1. Start printing a block-out job in accordance with the standard procedure.
2. After printing the first side, reinstall the media for the second side according to
the selected process (Head-tail or Head-head).
3. Align the media to the front edge of the print table according to the process.
4. Open the Blockout Sensor Calibration dialog, select Automatic
and choose Calibrate.
5. Make sure that the media is aligned with the front edge of the print table and
continue printing the second side.
To Next Page
