EG4 GRIDBOSS - Technical Specifications

1
1. TECHNICAL SPECIFICATIONS
GRID
NOMINAL AC VOLTAGE 120/240 VAC (L1/L2/N required)
FREQUENCY 60 Hz
MAXIMUM CURRENT 200A
SERVICE ENTRANCE RATED 22kAIC with 200A Eaton CSR2200N (CSR25K) breaker
GENERATOR
NOMINAL VOLTAGE 120/240 VAC (L1/L2/N required)
FREQUENCY 60 Hz
MAXIMUM CURRENT 125A
NON-BACKUP
NOMINAL VOLTAGE 120/240 VAC (L1/L2/N required)
FREQUENCY 60 Hz
MAXIMUM CURRENT 200A
BACKUP
NOMINAL VOLTAGE 120/240 VAC (L1/L2/N required)
FREQUENCY 60 Hz
MAXIMUM CURRENT 200A
HYBRID
NUMBER OF PORTS 3
NOMINAL VOLTAGE 120/240 VAC (L1/L2/N required)
FREQUENCY 60 Hz
MAXIMUM CURRENT PER PORT 90A*
SUPPORTED INVERTERS EG4
®
12kPV, 18kPV, FlexBOSS18 & FlexBOSS21**
SMART PORTS
NUMBER OF PORTS 4
NOMINAL VOLTAGE 120/240 VAC (L1/L2/N required)
FREQUENCY 60 Hz
MAXIMUM CURRENT PER PORT 1: 125A | 2: 80A | 3: 60A | 4: 60A
GENERAL DATA
COMMUNICATION INTERFACE RS485/Wi-Fi/CAN
IDLE CONSUMPTION ~55W
TRANSFER TIME ~25 ms
INTERNAL BUS RATING 350A (software limited to 200A)
INTERNAL FUSE RATING 315A
OPERATING ALTITUDE <6561 ft (<2000 m)
RELATIVE HUMIDITY 0 – 100%
OUTDOOR RATING NEMA 3R
OPERATING AMBIENT TEMPERATURE RANGE -40°F – 113°F (-40°C – 45°C)
PRODUCT DIMENSIONS (H×W×D) 31.5×19.7×7 in (800×500×178 mm)
UNIT WEIGHT 55 lbs. (25 kg)
STANDARD WARRANTY 10-year standard warranty***
*Install a properly sized breaker based on the connected inverter: 50A - 12kPV; 70A - 18kPV; 90A – FlexBOSS18 & 21.
**Third-party inverters are not supported and cannot be connected to the hybrid ports.
***For information regarding warranty registration on EG4
®
Electronics products, please navigate to
https://eg4electronics.com/warranty/ and select the corresponding product to begin the registration process.
