Example Configurations:
Grid Sell Back: The inverter is configured for grid sell-back. AC coupling will be used as supplemental
power to the backup port, smart loads, non-backup port and to assist with charging the batteries. Once
the batteries are fully charged, AC-coupled power will continue to assist with powering loads. This
configuration will only work when grid input is present.
Off-Grid Mode: In this example, the AC coupling configuration only applies when no grid is present. If
the grid is present, the AC-coupled inverter will not output power. The inverter is configured for off-grid
mode, and AC coupling will be used as supplemental power to the backup port and the smart loads and
to assist with charging the batteries. Once the batteries are fully charged, AC-coupled power will
continue to assist with powering loads. In this configuration, the non-backup port cannot be powered
since the grid input cannot be active to support AC coupling in off-grid mode.
Inverter Settings:
Application:
Power Backup: Enable
Grid Sell Back: Enable
Fast Zero Export: Disable
Off-Grid Mode: Disable
Charge:
AC Charge: Enable
GridBOSS Settings:
Battery Control (Common Settings):
Charge Control: SOC
Discharge Control: SOC
Grid Boss Smart Port #:
Smart Port Mode: AC Couple
AC Couple Enable: Enable
AC Couple Start & End SOC%: 30% & 100%
AC Couple Start Time: 00:00
AC Couple End Time: 23:59
Inverter Settings:
Application:
Power Backup: Enable
Grid Sell Back: Disable
Fast Zero Export: Enable
Off-Grid Mode: Enable
Charge:
AC Charge: Enable
GridBOSS Settings:
Battery Control (Common Settings):
Charge Control: SOC
Discharge Control: SOC
Grid Boss Smart Port #:
Smart Port Mode: AC Couple
AC Couple Enable: Enable
AC Couple Start & End SOC%: 30% & 100%
AC Couple Start Time: 00:00
AC Couple End Time: 23:59
