EG4 LuxPowerTek 6000XP User Manual

34
Device Overview
All the inverters linked to the account can be found here. Clicking a serial number will
switch the main page to show the real time data for that inverter.
7.3.5 DASHBOARD (MAINTENANCE TAB)
The "Maintenance" view is used for firmware updates and to remotely change settings on
your inverter by selecting a station and then an inverter serial number.
Distributors can manage all settings for all inverters at once with the help of the batch setting
capability supported by EG4's monitor system.
Note: If trying to update firmware locally, see Section 8.
Important
Advanced technical knowledge is necessary to properly make changes. End users will
only be able to see the “Remote Set” tab to make changes to their inverter.
Remote Set

EG4 LuxPowerTek 6000XP Specifications

General

Category	Inverter
Rated Power	6000W
Max DC Input Power	7800W
Number of MPPT Trackers	2
Battery Voltage	48V
Max Charge/Discharge Current	120A
Protection Degree	IP65
Frequency	50/60Hz
Model	LuxPowerTek 6000XP
Communication	RS485
Operating Temperature Range	-25°C to 60°C
Protection Features	Over Voltage Protection, Over Temperature Protection
Cooling	Fan
