EG4 LuxPowerTek 6000XP User Manual

44
11. LCD SETTINGS
There are four (4) buttons on the LCD screen used to
select various modes and make changes to settings:
Step 1: Press the Enter button for ≈3 seconds to enter
the setting mode. The data in the ‘General Information
Display Area’ will flash and the 2-digit Setting field will be
displayed.
Step 2: Press Up/Down to cycle through the setting
settings (1-29).
Step 3: Press Enter to confirm the desired setting.
Step 4: Press Up/Down to cycle through the settings.
Step 5: Press Enter to confirm the desired setting.
# Description Setting Option(s)
1
Date & Time
This setting allows the user to set the Local Date and Time.
2
PV Input Mode
This setting allows the user to
set the PV Input Mode.
PV Input Type:
S=two independent strings,
P=same string input for 2
MPPTs
Default: S

EG4 LuxPowerTek 6000XP Specifications

General

Category	Inverter
Rated Power	6000W
Max DC Input Power	7800W
Number of MPPT Trackers	2
Battery Voltage	48V
Max Charge/Discharge Current	120A
Protection Degree	IP65
Frequency	50/60Hz
Model	LuxPowerTek 6000XP
Communication	RS485
Operating Temperature Range	-25°C to 60°C
Protection Features	Over Voltage Protection, Over Temperature Protection
Cooling	Fan
