EG4 LuxPowerTek 6000XP User Manual

57
MAXIMUM UTILIZED SOLAR POWER
8000W (4000W per MPPT)
RECOMMENDED MAXIMUM SOLAR INPUT
10,000W
EFFICIENCY
MPPT EFFICIENCY
99%
BATTERY CHARGING EFFICIENCY
93%
BATTERY DISCHARGING EFFICIENCY
93%
IDLE CONSUMPTION (STANDBY MODE)
*
w/ PV
<30W
w/ Battery
≈50W
w/ AC
<50W
BATTERY DATA
TYPE
Lead-acid/Lithium
MAX. DISCHARGE CURRENT
140A
MAX. CHARGE CURRENT
125A **
NOMINAL VOLTAGE 48 VDC
BATTERY VOLTAGE RANGE 46.4-60 VDC (Lithium); 38.4-60 VDC (Lead-Acid)
REC. BATTERY CAPACITY PER INVERTER >200Ah
HIGH DC CUT-OFF VOLTAGE 59VDC (Lithium) | 60VDC (Lead-acid)
HIGH DC RECOVERY VOLTAGE 57.4VDC(Li) | 58VDC(Lead-Acid)
LOW DC WARNING VOLTAGE
57.4VDC (Lithium)
LOAD<20% 44.0 VDC (Configurable)
20%≤LOAD<50% Warning Voltage @Load <20% - 1.2V
LOAD≥50% Warning Voltage @Load <20% - 3.6V
LOW DC WARNING VOLTAGE RETURN Low DC Warning Voltage @Dierent Load +2V
LOW DC CUT-OFF VOLTAGE
LOAD<20% 42.0VDC (Configurable)
20%≤LOAD<50% Cut-O Voltage @Load <20% - 1.2V
LOAD≥50% Cut-O Voltage @load <20% - 3.6V
LOW DC CUT-OFF RETURN VOLTAGE
CUT-OFF VOLTAGE
@LOAD <20%
≥45V
Low DC Cut-O Voltage @load <20% +3V
CUT-OFF VOLTAGE
@LOAD <20%
<45V
48V
LOW DC WARNING SOC
20% SOC (Configurable)
LOW DC WARNING RETURN SOC
Low DC Warning SOC +10%
LOW DC CUT-OFF SOC
15% SOC (Grid ON) (Configurable)
15% SOC (Grid OFF) (Configurable)
LOW DC CUT-OFF RETURN SOC
Low DC Cut-O SOC +10%
CHARGE CUT-OFF VOLTAGE
58.4VDC
GENERAL DATA
MAX. UNITS IN PARALLEL
16
INTEGRATED DISCONNECT
Yes
DC SWITCH RATING FOR EACH MPPT
Yes
DIMENSIONS
18×25.5×5.25 in (457×648×132mm)
WEIGHT
52.9 lbs. (24kg)

EG4 LuxPowerTek 6000XP Specifications

General

Category	Inverter
Rated Power	6000W
Max DC Input Power	7800W
Number of MPPT Trackers	2
Battery Voltage	48V
Max Charge/Discharge Current	120A
Protection Degree	IP65
Frequency	50/60Hz
Model	LuxPowerTek 6000XP
Communication	RS485
Operating Temperature Range	-25°C to 60°C
Protection Features	Over Voltage Protection, Over Temperature Protection
Cooling	Fan
