USER MANUAL INFUSOVET CONNECT INFUSION PUMP
T +49 7461 96 580 0 | F +49 7461 96 580 90 | export@eickemeyer.com | www.eickemeyer.com
3.4 Rear View
① Handle
② Drop sensor bracket
③ DB15 Multi-functional interface, with following functions
• DC power input interface
• Software uploading interface
• Nurse call interface
• Drop sensor interface
Note!
The above functions cannot be used at the same time.
④ Clamp
⑤ Product label
⑥ AC / DC Adapter Port
⑦ Loudspeaker
3.5 Drop Sensor (Optional, Item No. 40209001)
②
①
③
① Housing
② Slider
Push the slider to left direction to adjust the spacing, loosen the slider to automatically return.
③ Cable
