24
USER MANUAL INFUSOVET CONNECT INFUSION PUMP
T +49 7461 96 580 0 | F +49 7461 96 580 90 | export@eickemeyer.com | www.eickemeyer.com
6.2.2 Infusion Apparatus Installation
1. Open the pump door left and open it.
2. Push the anti-fl ow free clip to the lower.
3. Gently pull the infusion tube, straighten it, and fi x the infusion tubing the tube groove at both ends from top to bottom,
and close the anti-free fl ow clip to clamp the infusion tube.
4. Close the pump door, then pop up the infusion tube selection interface, indicating that the infusion tube is installed
correctly. Otherwise you need to reinstall.
To Next Page
