USER MANUAL INFUSOVET CONNECT INFUSION PUMP
T +49 7461 96 580 0 | F +49 7461 96 580 90 | export@eickemeyer.com | www.eickemeyer.com
12. APPENDIX
Appendix A: Occlusion Response Property
Occlusion Pressure (mmHg) Flow Rate (ml/h)
Time to occlusion
Alarm (h:m:s)
Max bolus (ml)
1 50
0.1 01:44:10 0.137
1 00:10:58 0.178
25 00:00:15 0.134
5 900
0.1 35:07:19 0.102
1 01:50:32 0.172
25 00:04:22 0.132
Note!
• The alarm pressure intensity error is ± 40mmHg when the occlusion alarm level is 1.
• The alarm pressure intensity error is ± 125mmHg when the occlusion alarm level is 2 – 4.
• The alarm pressure intensity error is ± 180mmHg when the occlusion alarm level is 5.
Note!
• Conditions for above testing data: infusion set brand EICKEMEYER®.
• The occlusion alarm pressure, alarm delay time and bolus are infl uenced by the test conditions, temperature
and line length. (The increase in line length will lead to the increase of alarm delay. Lower temperature will
lead to poor elasticity of pipeline, exceeding the declared error range of blocking grade, resulting in inaccurate
alarm pressure. The shortening in line length and higher temperature have no effect).
• The above data is the typical value under the test conditions, please see the test data of the product for the
actual data, the data may be different if the test conditions are different
