7.1 SELECTING YOUR LANGUAGE
1 Press and hold the ON/OFF button until the Elcometer logo is
displayed.
2 Press Menu/Setup/Language and select your language using the
softkeys.
3 Follow the on screen menus.
To access the language menu when in a foreign language:
1 Switch the gauge OFF.
2 Press and hold the left softkey and switch the gauge ON.
3 Select your language using the softkeys.
7.2 SCREEN SETTINGS
A number of screen settings can be defined by the user via
Menu/Setup/Screen Settings including:
This can be set to ‘Manual’ or ‘Auto’ - the Screen Brightness;
brightness is adjusted automatically using the gauge’s ambient
light sensor.
Screen Timeout; The display will dim if inactive for more than
15 seconds and will go ‘black’ if inactive for the period defined.
Press any key or tap the gauge to awaken it.
7.3 SETTING UP THE READING DISPLAY
The colour LCD display is split into two halves; Top Display and Bottom
Display. The user can define what information is displayed in each half
including: Readings, Statistics, Run Chart, Bar Graph and Readings &
c
Differential .
7 SETTING THE GAUGE PARAMETERS
3 Compare the reading with the measurement foil thickness value
as printed on the foil label.
b
The reading should be within ±2% or 10µm (0.4mils) of the
measurement foil thickness value. If outside this range, zero the
probe (see Section 12 ‘Zeroing the Probe’ on page en-24) and repeat
the process. If the gauge is still outside specification - contact
Elcometer or your local supplier for further advice.
6 VERIFYING THE GAUGE & PROBE PERFORMANCE (continued)
www.elcometer.com
en-10
R
b
Whichever is the greater
c
Not available in ‘Scan Mode’ - see Section 5.3 ‘Taking a Reading in Scan Mode - Model T’ on page en-8.
