Elcometer 500 - 22 TECHNICAL SPECIFICATION

www.elcometer.com
en-34
R
22 TECHNICAL SPECIFICATION
Model
Model B
Model T
Thickness
Range
f
Using C1 Probe: 0.15 - 2.50mm (6 - 98mils)
Using C2 Probe: 0.75 - 10mm (30 - 390mils)
Accuracy
h
±2% or ±10µm (±2% or 0.4mils)
Resolution
(user selectable)
Low: 10µm, 0.01mm, 1mils or 0.001"
High: 1µm, 0.001mm, 0.1mils or 0.0001"
Measurement
i
Rate
60+ readings per minute
Gauge Memory
None
100,000 readings in up to
1,000 batches
Operating
Temperature
-10 to 50°C (14 to 122°F)
Power Supply
2 x AA batteries
(rechargeable batteries can be used)
j
Battery Life
Alkaline: Approximately 15 hours
Lithium: Approximately 28 hours
Gauge Weight
161g (5.68oz)
including batteries, without probe
Gauge
Dimensions
141 x 73 x 37mm (5.55 x 2.87 x 1.46")
without probe
Can be used in accordance with:
ASTM D6132, SSPC-PA 9, ISO 2808 Method 10
f
Epoxy coatings, thickness on other materials may vary.
h
Whichever is the greater.
I
140+ readings per minute when using the Model T in Scan Mode.
j
When in continuous reading mode. Rechargeable batteries may differ.
