Elcometer 500 - 1 GAUGE OVERVIEW; 2 BOX CONTENTS

1 GAUGE OVERVIEW
1 USB Data Output Socket (below cover)
2 LED Indicators - Red (left), Green (right)
3 LCD Display
4 Softkeys
5 On/Off Key
6 Probe Socket
7 Probe Plug
8 Probe
9 Probe Tip Collar
10 Replaceable Probe Tip
11 Wrist Strap Connection
12 Battery Compartment (¼ turn open/close)
2 BOX CONTENTS

Elcometer 500 Coating
Thickness Gauge

Probe Tip Oil; 4ml (0.14fl oz Bottle)

Ultrasonic Couplant;
120ml (4fl oz Bottle)

AA Batteries; x2

Protective Case

Transit Case (Model T only)

Wrist Harness

Screen Protector; x3

®
ElcoMaster Software (Model T only)

USB Cable (Model T only)

Test Certificate

User Guide
11
12
1
3
5
2
4
6
7
1
8
10
9
www.elcometer.com
en-3
R
Note: The Elcometer 500 is supplied as a gauge only
without probe - probes must be ordered
separately, see Section 20.1 ‘Probes’ on
page en-31.
