Technical Support - MDM 63/97 599 76 11-68 Rev. 01
Alarm
Description
Possible fault
Machine status/action
Reset
E41
Door open
Check whether the door is closed properly;
Wiring faulty; Door safety interlock faulty;
Main circuit board faulty.
Cycle paused
START/RESET
E42
Problems with door lock
Wiring faulty; Door safety interlock faulty;
Electrical current leak between heating element and ground;
Main PCB faulty.
Cycle paused
START/RESET
E43
Faulty TRIAC supplying power to
door delay system
Wiring faulty; Door safety interlock faulty;
Main circuit board faulty.
(Safety drain cycle)
Cycle blocked
RESET
E44
Faulty sensing by door delay system
Main circuit board faulty.
(Safety drain cycle)
Cycle blocked
RESET
E45
Faulty sensing by door delay system
TRIAC
Main circuit board faulty.
(Safety drain cycle)
Cycle blocked
RESET
E51
Motor power TRIAC short-circuited
Current leakage from motor or from wiring; Main PCB faulty.
Cycle stops with door open
(after 5 attempts)
ON/OFF
E52
No signal from motor tachometric
generator
Wiring faulty; Motor faulty;
Main circuit board faulty.
Cycle stops with door locked
(after 5 attempts)
ON/OFF
E53
Faulty sensing by motor TRIAC
Main circuit board faulty.
Cycle blocked
RESET
E54
Motor relay contacts sticking
Current leakage from motor or from wiring; Main PCB faulty.
Cycle blocked
(after 5 attempts)
RESET
E61
Insufficient heating during washing
Wiring faulty; NTC probe for wash cycle faulty; Heating element
faulty; Main PCB faulty.
The heating phase is skipped
START/RESET
E62
Overheating during washing
(temperature higher than 88°C
for more than 5 min.)
Wiring faulty; NTC probe for wash cycle faulty; Heating element
faulty; Main PCB faulty.
Safety drain cycle
Cycle stops with door open
RESET
E66
Heating element power relay faulty
(inconsistency between sensing
and relay status)
Main PCB faulty;
Safety water fill
Cycle stops with door closed
ON/OFF
RESET
E68
Earth leakage
Earth leakage between heating element and earth.
The heating phase is skipped
START/RESET
E69
Heating element interrupted
Wiring faulty; Heating element for washing interrupted
(thermal fuse open); Main circuit board faulty.
----------------
START
ON/OFF
RESET
E6A
Heating relay sensing faulty
Main circuit board faulty.
Cycle stops with door locked
RESET
E6B
(E6H)
Heating element power relay faulty
(inconsistency between sensing
and relay status)
Wiring faulty; Earth leakage between heating element and earth;
Main PCB faulty.
Safety water fill
Cycle stops with door closed
ON/OFF
RESET
E71
NTC probe for wash cycle faulty
(short-circuited or open)
Wiring faulty; NTC probe for wash cycle faulty;
Main circuit board faulty.
The heating phase is skipped
START/RESET
E72
Output drying NTC failure
Output drying NTC defective; Wiring or WD board defective
Drying heating phases skipped
START/RESET
E73
Input drying NTC failure
Input drying NTC defective; Wiring or WD board defective
Drying heating phases skipped
START/RESET
