Technical Support - MDM 64/97 599 76 11-68 Rev. 01
Alarm
Description
Possible fault
Machine status/action
Reset
E74
NTC probe for wash cycle
improperly positioned
Wiring faulty; NTC probe for wash cycle improperly positioned;
NTC probe faulty; Main PCB faulty.
The heating phase is skipped
RESET
E83
Error in reading selector
Main PCB faulty (incorrect configuration data).
Cycle cancelled
START/RESET
E84
Recirculation pump / Motor fan triac
sensing failure
Main board defective
Safety Drain cycle.
Cycle stops with door unlocked
RESET
E85
Recirculation pump / Motor fan triac
alarm
Recirculation pump or motor fan defective; Wiring or main board
defective
Safety Drain cycle.
Cycle stops with door unlocked
RESET
E86
Selector configuration error
Display board.
----------------
START
ON/OFF
RESET
E87
Display board microprocessor
faulty
Display board.
No action to be taken
START
ON/OFF
RESET
E91
Communication error between
main PCB and display
Wiring faulty; Control/display PCB faulty;
Main circuit board faulty.
----------------
RESET
E92
Communication inconsistency
between main PCB and display
(incompatible versions)
Incorrect control/display PCB;
Incorrect PCB (does not correspond to the model).
Cycle blocked
ON/OFF
E93
Appliance configuration error
Main PCB faulty (incorrect configuration data).
Cycle blocked
ON/OFF
E94
Incorrect configuration of washing
cycle
Main PCB faulty (incorrect configuration data).
Cycle blocked
ON/OFF
E97
Inconsistency between programme
selector and cycle configuration
Main PCB faulty (incorrect configuration data).
Cycle blocked
RESET
E98
FCV_MB protocol incong. Error
Main board incompatible with FCV control board
Cycle blocked
OFF/ON
E9C
Display board configuration error
Display board faulty.
----------------
START
ON/OFF
RESET
E9E
UI touch fault
Display Board
No actions
OFF/ON
EA1
DSP system failure
Wiring or main board defective; DSP sensor failure; Main motor belt
broken
Skip of the drum positioning phase
START/RESET
EA6
DSP door open failure
Wiring or main board defective; DSP sensor failure; Main motor belt
broken; Lid open
Cycle paused
START/RESET
EB1
(EH1)
Power supply frequency out of limits
Wrong or disturbed Power Supply line. Main board defective
Wait for nominal power supply
conditions
OFF/ON
EB2
(EH2)
Power supply voltage too high
Wrong or disturbed Power Supply line. Main board defective
Wait for nominal power supply
conditions
OFF/ON
EB3
(EH3)
Power supply voltage too low
Wrong or disturbed Power Supply line. Main board defective
Wait for nominal power supply
conditions
OFF/ON
EB4
(EH4)
Zero Watt relay alarm
Main board defective
No actions
OFF/ON
RESET
EBD
(EHD)
Heater WD relay sensing alarm
Main board defective
Cycle blocked
with door locked
RESET
