Electrolux EWF1284EDW - Page 65

Technical Support - MDM 65/97 599 76 11-68 Rev. 01
Alarm
Description
Possible fault
Machine status/action
Reset
EC1
Electronically controlled valve
blocked with operating flow meter
Faulty wiring; Faulty/blocked solenoid, PCB faulty.
Cycle stops with door locked
Drain pump continues to operate
(5 min. on, then 5 min. off. etc.)
RESET
EC4
AGS current sensor faulty
Main board faulty.
Spin speed reduced to safety speed
of 150 rpm
RESET
ED1
WD board communication alarm
WD board defective; Wiring between MB and WD,
Main Board defective, UI defective, Weight defective, FCV defective
Cycle blocked
START
ON/OFF
RESET
ED2
WD heating element1 relay failure
WD board defective; wiring, thermostats defective;
Main Board defective
Skip drying phase
START
ON/OFF
RESET
ED3
WD heating element1 sensing relay
failure
WD board defective
Skip drying phase
START
ON/OFF
RESET
ED4
WD heating element2 relay failure
WD board defective; wiring, thermostats defective,
Main Board defective
Skip drying phase
START
ON/OFF
RESET
ED5
WD heating element2 sensing relay
failure
WD board defective
Skip drying phase
START
ON/OFF
RESET
ED6
WD thermostat sensing failure
WD board defective
No actions
START
ON/OFF
RESET
ED7
WD thermostat failure
Manual or automatic; thermostat opened, wiring , WD board defective
No actions
START
ON/OFF
RESET
ED8
WD fan motor tachometer absent
Fan Motor defective
Fan Motor Wiring or WD board defective
Skip drying phase
ON/OFF
RESET
ED9
WD fan motor driving circuit alarm
WD board defective
Skip drying phase
ON/OFF
RESET
EDA
WD Power Supply alarm
Wrong or disturbed Power Supply line. WD board defective
Wait for nominal power supply
conditions
START
ON/OFF
RESET
EDB
(EDH)
WDM microcontroller fault
WDM board defective
No actions to be performed. If still
present replace the WDM Board
START
ON/OFF
RESET
EDC
WDM heating element opened
Drying heating elements opened, unplugged, or wiring
No actions
START
ON/OFF
RESET
EDD
WDM Ground Current leakage alarm
Current leakage between drying heater element and earth
Drying phases skipped.
START
ON/OFF
RESET
