43. Cabinet
Service
manual
487 03 29 41
6
43
Sliding Door
Door gasket
Check that the loading door gasket is clean
and in good condition. Use a suitable cleaner.
Do not use solvents that may damage sensitive
plastics or painted finish.
Check that felt packing A is intact and in good
condition.
There must be a maximum of 2 mm between
steel frame and felt, fig 1.
Adjusting of space is done by Loosen screws B
holding gliding shoe and pushing the doors into
place, fig 2.
There must be a maximum of 2 mm between
steel frame and felt.
Check and tighten all screws B (with 6 Nm)
holding the gliding shoes.
1
2
A
A
Max. 2 mm
B
B
B
B
B
B
B
B
B
