Electrolux T3900 - Page 89

487 03 29 41
5
42. Drum with bearing
Service
manual
42
8
Replacing supporting rollers, bearing or drum
Continued on the following page
h) Dismount 4 screws H at the bottom of
the front plate, fig 8.
i) Dismount 4 screws I at the top of the front
plate, fig 9.
j) Lift off the front plate, fig 10.
Continued on the following page.
H
9
I
10
