487 03 29 41
13
42. Drum with bearing
Service
manual
42
(continued from the previous page)
Removing Sliding Door equipment:
Recommended for removing the
drum.
• Disconnect the power to the dryer
1. Removing side screens P in filter
compartment:
2. On the side panel with the door
switch, remove rivets using a chisel
or a drill. Do not remove the top and
bottom rivets. This means that the
panel is only secured at the top and
the bottom.
3. Remove the wire: Adjust a board to
555 mm for securing doors.
See section 43 Replacing of wire rope
Continued on the following page
1
P
2
555 mm
