42. Drum with bearing
Service
manual
487 03 29 41
14
42
Removing Sliding Door equipment:
(continued from the previous page)
4. Carefully lower the doors onto the
rubber buffers R.
Take care! They weigh 24 kg.
Dismantle the 2 cross members D by
unscrewing the 3 screws E on either
side and pull the members towards
the clock:
5. Remove the door for the heating unit.
Continued on the following page
4
5
D
D
R
L
R
E
