Additional information for commissioning
Resetting the ELKO SmartHUB
Delete existing settings from an ELKO SmartHUB for commissioning or to remove
a hub from the ELKO Smart system. It may also be necessary to restore the
firmware in a hub to fix a problem.
The reset tool supplied with the hub is required.
There are two reset options:
• Level 1 reset (Restores Ethernet/WLAN settings only)
• Level 2 reset (Upon successful reset, all configuration data, user data, and
network data are deleted).
1. (See A) Locate the Reset button on the side of the hub.
2. Do one of the following:
– Level 1 reset: Press and hold the Reset button for 5 to 10 seconds.The
Ethernet LED (B) and WLAN LED (C) on the front of the hub both blink
once.
– Level 2 reset: Press and hold the Reset button for more than 15 seconds.
The Ethernet LED (B) and WLAN LED (C) on the front of the hub both
blink 3 times.
3. Release the Reset button.
The hub restarts. This takes about 40 seconds.
After a Level 2 reset, all settings are restored to their original default values and all
imported files are cleared. The latest firmware is also downloaded from the current
active host and installed, similar to other devices, the settings are factory reset.
Resetting ELKO Smart devices
Refer to the device user manual for reset instructions. See Supported devices,
page 10 for links to the device user manuals.
SUG_ELKO_Norway_04 41
