➑ SPECIFICATIONS
8-1 GENERAL
Item
Specifications
Power source
DC5V （AC adapter AC100 ～ 240V）
Power consumption
7.0W
Outside dimensions
W391.7 x D230.0 x H427.9mm (When setup)
W183.0 x D230.0 x H482.8mm (When folded)
Weight
Approx. 2.4kg (Main body only)
Output terminal
RGB input Mini Dsub 15P connector, female x 1
HDMI output terminal x 1
Ext. control terminal
USB device (2.0 compliant) Mini-B receptacle x 1
8-2 MAIN CAMERA
Item
Specifications
Lens
ｆ=4.0mm ～ 48.0mm F3.2～F3.6
Frame rate
30fps
Shooting area
Focus working range
TELE：200mm ～ ∞
WIDE：50mm ～ ∞
Optical zoom
12x
Digital zoom
8x (max.4x when using RGB output)
Focus
Manual（Push） / Zoom Sync
Image pick-up
element
1/2.8” CMOS 3.4mil pixels
Total pixels
H: 2144 / V: 1588
Effective pixels
H: 1920 / V: 1440
Sync. signal
Internal
Resolution
HDMI 1080i Horizontal: 800TV lines or more
Vertical: 800TV lines or more
Max.
Min.
1080i
433.1mm
240.1mm
46.9mm
26.4mm
XGA
433.1mm
322.5mm
46.9mm
35.2mm
