■MOVING PARTS OF THE TX-1
The camera head of the TX-1 can be moved as shown below.
※Depending on the position of the camera head or the installation place of the TX-1, stable
operation may not be possible. In that case, change the position of the base plate.
※In order to prevent the damage to the camera head, pay attention to the position of the
camera head when moving the camera head.
CAUTION
Be careful not to pinch your fingers when moving the arm or camera head.
90°
90°
90°
180°
64.5°
90°
P.39
P.9
◆Movable range
