Mechanical Adjustment
, Turn the embroidery unit upside down.
Remove the setscrews
t, y and u.
y
y
t
y
u
. Turn the embroidery unit again.
Push down the carriage arm release lever
q.
Retract the carriage arm to the stored position.
q
i
⁄0
Move the carriage arm as far as it goes in the direction of
arrow
i.
⁄1 Move back the carriage arm slightly (approximately 5 mm)
so the rounded part of the carriage arm
o meets the hole
of the embroidery unit cover
!0.
o
!0
