114 Chapter 4
9 LOWER CASE W/
SPEAKER
ASSY L-CASE YUKON 60.N2401.001
SPEAKER
N/A SPEAKER SPEAKER BIWA 23.TK501.002
CASE/COVER/BRACKET ASSEMBLY
7 UPPER CASE W/
COVER SWITCH
CABLE
ASSY U-CASE YUKON 60.N2401.002
5 MIDDLE COVER ASSY MIDDLE COVER
YUKON
42.N2401.001
CPU/PROCESSOR
N/A CPU AMD ATHLON
2650E AM2+ 1.6G
512K 800 940 G2 15W,
ADG2650IAV4DP
IC CPU ATHLON
2650E 1.6G G2
KC.AE002.265
COMBO MODULE
12 ASSEMBLY COMBO
MODULE 24X
ODD NCB24XS FOR
YUKON
6M.N2401.001
N/A OPTICAL BRACKET BRKT ODD BIWA 33.TK501.002
N/A COMBO BEZEL ASSY ODD BEZEL
COMBO YUKON
42.N2401.003
NO. PART NAME DESCRIPTION ACER PART NO.
To Next Page
